Midas DL152 Digital Stage Box with 24 Line Outputs and Dual AES50 Ports
6,218.10 AED Included (5% UAE VAT)
The DL152 is a 2U 19" rack I/O unit with 24 line level outputs, featuring dual-redundant AES50 network ports. It ensures the renowned Midas sound quality and is compatible with Midas PRO and M32 Series digital consoles, making it perfect for reliable digital snake connections.
Model number
DL152
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
Midas DL152 Digital Audio Interface
The DL152 is a robust 2U 19″ rack I/O unit featuring 24 line level outputs, designed to deliver exceptional Midas sound quality using our proven technologies. Equipped with two AES50 network ports for dual redundancy, it seamlessly integrates with Midas PRO and M32 Series digital consoles, facilitating a reliable digital snake connection from front of house to stage.
Features
- 24 electronically balanced low impedance line level outputs
- Remote operation up to 100 m via CAT5/5e cable
- Selectable 96 kHz or 48 kHz sample rate operation
- Fully programmable from front panel controls or console
- PSU status indicator LEDs and configuration LCD display on front panel
- Supports dual redundant AES50 networks
- Features Neutrik etherCON AES50 network ports
- Rugged 2U rackmount chassis for portable applications
- Auto-ranging universal switch-mode power supply
Specifications
| Parameter | Details |
|---|---|
| Sample Rate | 48 kHz, 96 kHz |
| Dynamic Range | >107 dB unweighted (20 Hz – 20 kHz) |
| Maximum Output Level | +21 dBu into 600 Ω |
| Output Noise (Unity Gain) | -86 dBu |
| Frequency Response | ±0.5 dB (20 Hz – 20 kHz, relative to 1 kHz) |
| THD+N (Unity Gain) | <0.01% |
| Crosstalk @ 1 kHz | <-90 dB |
| Analogue Outputs | 24 |
| Type | Line Level |
| Connector | 3-pin XLR Balanced |
| Output Impedance | 50 Ω |
| D/A Conversion | 24 bit, 96 kHz with 128 times oversampling |
| Network Connections | 2 |
| Connector | Neutrik etherCON with status LEDs |
| Redundancy | Dual cable redundancy |
| Network Interface | Conforms to AES50-2011 |
| Ethernet Control Port | 1 |
| Connector | Neutrik etherCON with status LEDs |
| Power | 1 |
| Connector | IEC mains inlet |
| Mains Input Voltage | 100 to 240 VAC, 50-60 Hz |
| Power Consumption | <150 W |
| Dimensions | 483 x 416 x 88 mm (19.0 x 16.4 x 3.5″) |
| Net Weight | 6.9 kg (15.2 lbs) |
| Operating Temperature Range | +5°C to +45°C |
| Storage Temperature Range | -20°C to +60°C |
