Yamaha DBR12 12-Inch 2-Way Powered Loudspeaker 1000W Class-D
1,732.50 AED Included (5% UAE VAT)
The Yamaha DBR12 is a 12" 2-Way Powered Loudspeaker with up to 1000W dynamic output via its Class D amplifier, featuring a 12" woofer and 1.4" high-frequency driver, maximum output of 131 dB, on-board 2-channel mixer, and versatile connectivity options including 1/4", XLR, and RCA connectors; it offers flexibility for floor monitoring, front of house, or rigged applications, combined with an ergonomic handle and lightweight design for easy portability.
Model number
DBR12
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
Yamaha DBR12 – 12″ 2-Way Powered Loudspeaker
The Yamaha DBR12 is a versatile 12″ 2-way powered loudspeaker suitable for a variety of applications including floor monitoring, front-of-house, and rigged installations. With up to 1000W of dynamic output provided by its Class-D amplifier, it delivers high efficiency and superb sound clarity. The DBR12 is constructed with portability in mind, ensuring easy transport and setup.
Features
- High-Efficiency Class D Amplifier providing up to 1000W of power
- Custom Designed Transducer for powerful bass and accurate mid/high frequencies
- Durable and Portable Cabinet with ergonomic handles
- Optimized 50° wedge angle for floor monitoring
- On-Board 2-Channel Mixer with versatile input options
- Equipped Rigging Points for installation applications
Specifications
| Specification | Details |
|---|---|
| Configuration | Active 2-Way |
| Enclosure Type | Bass-Reflex Loudspeaker |
| Total Power Capacity | 1000 W Peak, 465 W RMS |
| Amplifier Power Rating | LF: 800 W Peak, 400 W RMS; HF: 200 W Peak, 65 W RMS |
| HF Driver | 1 x 1.4″ Compression Driver |
| LF Driver | 1 x 12″ Woofer |
| LF Voice Coil | 2″ / 5.1 cm |
| Magnet | HF: Ferrite, LF: Ferrite |
| Frequency Range | 52 Hz to 20 kHz -10 dB |
| Maximum SPL | 131 dB SPL |
| Coverage Angle | 90° H x 60° V |
| Audio I/O | 2 x Combo XLR-1/4″ TRS Input, 1 x Stereo RCA Unbalanced Line Input, 1 x XLR 3-Pin Output |
| Crossover | 2.1 kHz |
| AC Input Power | 100 to 120 VAC, 50 / 60 Hz |
| Power Consumption | 74 W (1/8 Power), 18 W (Idle) |
| Mounting | 1 x 1.38″ Pole Socket, 2 x M8 (Bottom), 1 x M8 (Rear) |
| Handles | 2 x Side |
| Cooling | Fan (Variable Speed) |
| Construction Material | Plastic |
| Dimensions | 14.8 x 23.7 x 13.7″ / 376 x 601 x 348 mm |
| Weight | 34.8 lb / 15.8 kg |
| Package Weight | 43.3 lb |
| Box Dimensions (LxWxH) | 27.5 x 18 x 18″ |
