Tascam 4-Channel Line Output Dante Converter ML-4D/OUT-E with DSP Mixer
2,711.10 AED Included (5% UAE VAT)
The ML-4D/OUT-E is a compact converter designed to transform Dante input signals into 4-channel line outputs, fitting seamlessly into various Dante systems. Occupying half the space of a standard 1U rack, it includes a built-in DSP mixer for optimal performance in small-scale setups, supporting up to 96kHz/24bit resolution with Euroblock connectors for analog outputs.
Model number
ML-4D/OUT-E
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
TASCAM ML-4D/OUT-E Dante Compact Processor
The ML-4D/OUT-E is a versatile and compact converter designed to convert Dante input signals into 4-channel line output signals. Occupying just half the size of a standard 1U rack, it serves as the perfect analog output unit for various Dante systems. This model includes a built-in DSP mixer, ensuring optimal performance in small-scale setups with other models from the TASCAM Dante Compact Processor Series.
Supporting up to 96kHz/24bit resolution, the ML-4D/OUT-E employs Euroblock connectors for its analog line outputs. Its robust design and powerful features make it an essential equipment in diverse professional audio environments.
Features
- 4 line output channels
- 4 Dante input/output channels
- Supports Power over Ethernet (PoE)
- Sample rates up to 96kHz/24bit
- Built-in DSP functions for enhanced usability
- Dante daisy chain capability
- Compatible with Dante Domain Manager and AES67 modes
- Up to 50 flexible scene presets
- Future support for timer event functionality
- Control software available for Windows, Mac, iOS, and Android
- Remote control via GPI and Dante
- Half-rack mountable size
- Indicators for LAN/Dante connection status and sample rate
- Signal indicators for line output monitoring
- Configurable reference levels via remote control
- Surface rack mountable angles for under-desk installation included
- Optional accessories: redundant power supply adapter, rack-mountable shelf
Specifications
| Specification | Details |
|---|---|
| Resolution & Channels | 44.1/48/88.2/96kHz, 16/24-bit, 4 channels |
| DATA/DATA+PoE Connectors | RJ-45 |
| Transmission Protocol | Dante |
| Ethernet Standard | 1000BASE-T (IEEE 802.3ab) |
| Ananlog Output Connectors | Balanced Euroblock, 3.81 mm pitch |
| Nominal Output Levels | +4 dBu or +6 dBu |
| Maximum Output Level | +15 dBu to +24 dBu (switchable) |
| Output Impedance | 200 Ω or lower |
| Control Connectors | Euroblock 3.81 mm pitch |
| Power Source | PoE class 0, optional TASCAM PS-P1220E adapter |
| Power Consumption | 4W |
| Dimensions (W x H x D) | 214 x 44.45 x 136.1 mm |
| Weight | 863 g |
| Operating Temperature Range | 0°C to 40°C |
| Included Items | Installation brackets, Euroblock plugs, cable band kit, owner’s manual, warranty |
