500 in stock
Midas PRO LCD Pushbutton Switch 36×24 Pixel Display RGB LED Backlight – Set of 8
345.45 AED Included (5% UAE VAT)
PRO LCD SWITCH offers dynamic user interfaces with visual feedback and custom labeling for mixing console channels, buses, and groups, featuring a high-contrast FSTN LCD with 36x24 pixel resolution for clear viewing at wide angles, and a momentary switch action for reliable tactile feedback.
Model number
PRO LCD SWITCH
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
PRO LCD SWITCH
Experience the future of dynamic user interfaces with the PRO LCD SWITCH, designed for clear visual feedback and user-defined labeling of your mixing console’s channel, bus, and group selections. This innovative device features a high contrast FSTN LCD glass with 36 x 24 pixel resolution, offering unparalleled visibility from a wide vertical and horizontal viewing angle. The momentary switch action ensures reliable tactile response, crucial for mix engineers focused on live performance rather than their console.
Features
- Momentary action pushbutton switch with tactile feedback
- 36 x 24 pixel resolution dot matrix graphic LCD display
- RGB LED backlight for high visibility in all lighting conditions
- FSTN LCD Glass for high contrast and wide viewing angle
- 8 distinct displayable LED colors
- 2 wire serial data interface with up to 1 MHz operation
- Suitable replacement for Screenkeys* RGB24T LCD Switch in Midas XL8 and PRO SERIES consoles
Specifications
| Specification | Details |
|---|---|
| Pixel Matrix | 36 x 24 |
| LED Backlighting Colors | Red, Green, Blue, Magenta, Cyan, White, Pink, Yellow |
| Operating Voltage | 5 Volt DC (Nominal) |
| LCD Screen Size (L x W) | 19.5 x 16.1mm (0.77 x 0.63″) |
| Pixel Field Size (L x W) | 14.7 x 10.3mm (0.58 x 0.41″) |
| Maximum Data Rate | 1 MHz |
| Operating Temperature Range | 5 to 45 deg. C (41 to 113 deg. F) |
| Storage Temperature Range | -20 to 60 deg. C (-4 to 140 deg. F) |
| Dimensions | 0.9 x 0.9 x 1.2″ (2.29 x 2.29 x 3.05cm) |
Additional information
Additional information
| Brand |
|---|
