Midas HD96-24-CC-IP Live Digital Console 144 Channels 96 kHz
130,320.75 AED Included (5% UAE VAT)
The Midas HD96-24-CC-IP from the Heritage D series is a 144-input digital mixing console featuring eight Midas preamps, 120 mix buses, 24 VCA groups, and advanced digital effects. It includes 28 motorized faders, touch-sensitive controls, a 21-inch multi-gesture touchscreen, HyperMAC and AES50 networking, dual Ultranet ports, and a dual network bridge format converter, all supported by an integrated wireless transceiver module and dual redundant power supplies.
Model number
HD96-24-CC-IP
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
The Midas HD96-24-CC-IP is a prime example of professional-grade digital mixing technology, designed to meet the complex demands of live sound reinforcement and studio recording. As a centerpiece of the Heritage D series, it offers an extensive suite of high-end features and connectivity options.
Key Features
| Specification | Details |
|---|---|
| Input Channels | Up to 144 flexi channels |
| Mix Buses | 120 time-aligned and phase-coherent |
| VCA Groups | 24 variable control association groups |
| Display | 21″ full-color TFT with capacitive touch sensing |
| Sample Rate | 96 kHz |
| Digital Effects Engines | 24 multi-channel |
| Networking | HyperMAC and AES50 with up to 576 I/O @ 96 kHz |
| Motorized Faders | 28 Midas PRO 100mm |
| Connectivity | Dual Ultranet ports, Dual network bridge format converter |
| Wireless Module | Integrated wireless transceiver |
| Power Supply | Dual redundant, auto-ranging switch-mode |
Processing
| Input Processing Channels | 144 |
| Output Processing Channels | 96 flexi aux outputs, 24 matrices, stereo bus, mono bus |
| Point-to-point Routing Matrix | 622 x 652 |
| Signal Processing | 64-bit floating point |
Connectors
| Mic Preamplifiers | 8 x XLR balanced |
| Balanced Outputs | 8 x XLR balanced |
| Talkback Connector | 1 x XLR balanced |
| Digital AES3 Inputs/Outputs | 2 / 2 |
