Klark Teknik Dante Expansion Module DM80-DANTE 16×16 Channels with ULTRANET and Ethernet
2,576.70 AED Included (5% UAE VAT)
The DM80-DANTE is an expansion card designed for the Klark Teknik DM8000 Digital Audio Processor, enabling connection to external devices via the Dante protocol for audio transmission over an Ethernet network. It features dual RJ-45 connections for 16 x 16 channel networking of 24-bit/48 kHz audio, supports up to 100 meters of Cat5e cable, and offers PC remote control and configuration via Ethernet. Additionally, the ULTRANET connection outputs up to 16 audio channels simultaneously, maximizing the DM8000's processing capabilities even in third-party systems.
Model number
DM80-DANTE
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
The DM80-DANTE is a multichannel audio interface expansion card that enables the Klark Teknik DM8000 Digital Audio Processor to connect to external devices using the Dante high-performance digital media protocol to deliver audio over a standard Ethernet IP network. Dual RJ-45 connections share 16 x 16 channel networking of 24-bit / 48 kHz low-latency audio over Cat5e cable (max. 100 m / 330 ft.), while DM80-DANTE’s Ethernet connection provides comprehensive PC remote control and configuration. Additionally, a proprietary digital audio networking ULTRANET connection simultaneously outputs up to 16 channels of audio. The DM80-DANTE lets you harness all of the processing benefits of the DM8000, even when it is used in third-party system applications.
Features
- Dante* expansion module for Klark Teknik DM8000 etc. featuring Dante and ULTRANET audio networking
- Expands the processing benefits of DM8000 to third-party systems
- Dante enabled audio networking enables up to 16 input and 16 output channels
- ULTRANET digital audio networking for additional and simultaneous 16 output channels
- Full software configuration and control via integrated Ethernet port
- Dual RJ-45 connections for Dante primary and secondary networking interface
- Transformer-isolated design to eliminate ground loop interference
Specifications
| For Use with | DM8000 Digital Audio Processor |
| Connectors | 4 x RJ45 |
| Dante Interface | 2 x RJ45 for Dante primary and secondary networking Channels: 16 input and 16 output |
| Ultranet Input/Link | 1 x RJ45 Outputs: 16 |
| Ethernet | 1 x RJ45 |
| Transformer | Transformer-isolated design to eliminate ground loop interference |
| Dimensions | Not specified by manufacturer |
| Weight | Not specified by manufacturer |
Packaging Info
| Package Weight | 0.435 lb |
| Box Dimensions (LxWxH) | 6.6 x 4.05 x 1.85″ |
