500 in stock
Yamaha Powered Subwoofer DXS18XLF 18″ 1600W Class-D – Black
7,035.00 AED Included (5% UAE VAT)
The Yamaha DXS18XLF is a black powered subwoofer featuring an 18-inch woofer and a 1600W Class-D amplifier, offering a frequency range of 30 to 150 Hz (-10 dB) and a maximum SPL of 136 dB, ideal for enhancing the bass output of DZR-series powered loudspeakers.
Model number
DXS18XLF
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
Yamaha DXS18XLF Powered Subwoofer
The Yamaha DXS18XLF is an advanced powered subwoofer designed to extend the low-frequency capabilities of full-range speakers, making it an excellent companion for the DZR series powered loudspeakers. This subwoofer features a high-output 18-inch woofer and a powerful 1600W Class-D amplifier, delivering deep bass frequencies that enhance any sound system.
Key Features
- 18″ Woofer with 4″ Voice Coil
- 1600W Class-D Amplifier
- Frequency Range: 30 Hz to 150 Hz (-10 dB)
- Maximum SPL: 136 dB
- Durable Plywood Cabinet with Polyurea Coating
- Optional Accessories: Speaker Cover (SPCVR-DXS18X) and Wheel Kit (SPW-1)
D-XSUB LF Processing
The DXS18XLF utilizes a 96 kHz high-power DSP processor for sophisticated low-frequency management. This includes three modes:
- Normal Mode: Balanced low-frequency response.
- Boost Mode: Tighter and more punchy bass.
- Xtended LF Mode: Further extension of low-end frequencies.
DSP Protection
- Maximizes output and ensures component longevity.
- Precise DSP control for optimal limiter points set through extensive testing.
- Consistent monitoring of power supply, amplifiers, and transducers.
Specifications
| Specification | Details |
|---|---|
| Configuration | Active Subwoofer |
| Enclosure Type | Bass-Reflex Subwoofer |
| Total Power Capacity | 1600 W Peak / 1200 W RMS |
| Amplifier Class | Class-D |
| LF Driver | 1 x 18″ / 457.2 mm Woofer |
| LF Voice Coil | 4″ / 101.6 mm |
| Magnet | Ferrite |
| Frequency Range | 30 Hz to 150 Hz -10 dB |
| Maximum SPL | 136 dB |
| Max Input Level | Line Input: +24 dBu |
| I/O Impedance | Input: 20 Kilohms |
| Audio I/O | 2 x Combo XLR-1/4″ TRS Female Balanced/Unbalanced Input 2 x XLR 3-Pin Male Balanced Output |
| USB | 1 x USB-A (External Memory, Host Connection) |
| Maximum Sampling Rate | 96 kHz |
| AC Input Power | Universal: 100 to 240 VAC, 50 / 60 Hz |
| AC Power I/O | 1 x IEC (Locking) |
| Power Consumption | 40 W (Idle) / 180 W (1/8 Power) |
| Mounting | 1 x 1.4″ / 35 mm Pole Socket (Top) 1 x M20 Pole Socket (Top) |
| Handles | 1 x Each Side |
| Cooling | Fan (Variable Speed) |
| Construction Material | Plywood |
| Dimensions | 21.7 x 25.9 x 28.3″ / 550 x 657 x 720 mm |
| Weight | 107.8 lb / 48.9 kg |
| Package Weight | 125.5 lb |
| Box Dimensions (LxWxH) | 33 x 31 x 26.25″ |
