Yamaha Digital Mixing Console CL1 with 48 Mono and 8 Stereo Channels
85,296.75 AED Included (5% UAE VAT)
The Yamaha CL1 digital mixer is engineered for live sound and broadcast, providing exceptional audio quality and show management with support for up to 48 mono and eight stereo channels when connected to Rio series stage boxes (sold separately). It features 16 channel faders, two master faders, and Yamaha’s Virtual Circuitry Modeling for access to Neve Portico processors and other classic hardware emulations. Built-in Dan Dugan automatic mixing aids in optimizing microphone performance and minimizing feedback.
Model number
CL1
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
Yamaha CL1 Digital Mixer
Designed to excel in live sound and broadcast applications, the Yamaha CL1 digital mixer delivers outstanding sound quality and impressive show control. Connect Rio series stage boxes (not included) for up to 48 mono and eight stereo mixable channels, with 16 channel faders and two master faders for control. Yamaha’s Virtual Circuitry Modeling gives you access to Neve Portico 5033 EQ and Portico 5043 compressor/limiter processors, plus other spot-on emulations of classic hardware processors. And built-in Dan Dugan automatic mixing makes it easy for any operator to optimize microphones and effectively fight feedback. In short, world-class sound is easily attainable with the Yamaha CL1 digital mixer.
Key Features
- 16-fader digital mixing console
- 48 mono and 8 stereo mixable channels
- Connect up to 8 Rio series stage boxes (sold separately) for I/O
- Touchscreen display for intuitive control over the Centralogic user interface
- Built-in Dante interface plus 3 MY-card slots for digital expansion
- Control port for computer control (wired or Wi-Fi)
- Portico 5033 EQ and Portico 5043 compressor/limiter processors designed by Rupert Neve Designs
- Dan Dugan automatic mixing system easily optimizes microphone gain and fights feedback
- Nuendo Live and Dante Virtual Soundcard licenses included
Specifications
| Specification | Details |
|---|---|
| Type | Digital |
| Channels | 16 + 2 master faders, 48 mono channel mixing plus 8 stereo channels |
| Inputs – Mic Preamps | 8 x XLR |
| Phantom Power | 8 |
| Outputs – Other | 8 x XLR (line out) |
| Inputs – Digital | 2 x RJ-45 (Dante) |
| Outputs – Digital | 2 x RJ-45 (Dante), 1 x XLR (AES/EBU) |
| Busses/Groups | 16 send Mix bus, 8 send Matrix bus |
| Inserts | Internal |
| Talkback | 1 x XLR |
| MIDI I/O | In/Out |
| Data I/O | 1 x D-Sub GPI (15-pin female), 1 x Ethernet |
| Headphones | 1 x 1/4″ |
| USB | 1 x USB Type A |
| I/O Expansion Slots | 3 x Card slots available (DSP cards or mini-YGDAI cards) |
| Word Clock | In/Out |
| Faders | 18 x 100mm faders |
| EQ Bands | 4-band parametric channel EQ, 31-band Graphic EQ, 15-band flex EQ |
| Effects | Reverbs, Delays, Modulation, Premium Rack compressor modeling and more |
| DAW Control | Yes (via Dante) |
| Height | 11.75″ |
| Depth | 26.25″ |
| Width | 25.62″ |
| Weight | 52.9 lbs. |
| Manufacturer Part Number | CL1 |
