Turbosound TBV123-AN 2-Way 12-Inch 2500W Powered Loudspeaker
9,010.05 AED Included (5% UAE VAT)
The BERLIN TBV123-AN 2-Way 12" Constant Curvature Loudspeaker by Turbosound is a versatile 2500W powered system for touring, portable, and installed sound reinforcement, working independently without a controller for various applications like FOH, offstage fill, and distributed fill in venues such as nightclubs, concert halls, and houses of worship.
Model number
TBV123-AN
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
BERLIN TBV123-AN 2-Way 12″ Constant Curvature Loudspeaker
The BERLIN TBV123-AN from Turbosound is an advanced arrayable 2500W 12″ powered loudspeaker system, ideal for a variety of sound reinforcement applications including touring, portable setups, and installations. Suitable for a diverse range of venues, including nightclubs, concert halls, and houses of worship, this loudspeaker delivers exceptional audio performance whether used for FOH, offstage fill, stereo in-fill, or distributed fill applications.
Featuring a carbon fiber-loaded 12″ neodymium low-frequency driver and dual aluminum dome 1″ neodymium motor compression drivers, the TBV123-AN is engineered for superior sound quality. Its 100° horizontal by 15° vertical dispersion constant curvature Dendritic waveguide ensures a wide and controlled coverage area, minimizing reverberation.
Features
- Two-way, full-range loudspeaker for versatile applications
- Constant curvature Dendritic waveguide with 100 x 15° (H x V) dispersion
- 2500W output power with KLARK TEKNIK Class-D technology
- KLARK TEKNIK DSP for comprehensive system control
- ULTRANET digital audio networking compatibility
- 12″ neodymium LF driver with carbon fiber load
- Dual 1″ neodymium HF compression drivers with aluminum dome
- LCD display for user-friendly interface
- PC remote control software available
- Robust 3/4″ plywood enclosure with semi-matte black paint
- Integrated suspension hardware for efficient array setup
- Multiple M10 mount points for flexible attachment options
- Dual-angle pole mount for precise audience targeting
- Durable powder-coated perforated steel mesh grille
- Neutrik powerCON connectors for reliable power input and output
Specifications
| System | Details |
|---|---|
| Frequency Response | 65 Hz to 20 kHz ±3 dB / 53 Hz to 20 kHz -10 dB |
| Nominal Dispersion | H x V: 100 x 15° at -6 dB points |
| Maximum SPL | 131 dB peak |
| Crossover Type | Active |
| Transducers | 1 x 12″ LF driver / 2 x 1″ HF compression drivers |
| Limiter | Independent HF, LF, peak, and rms |
Amplifier
| Amplifier | Details |
|---|---|
| Maximum Output Power | 2500 W |
| Type | Class-D |
| Protection | Short-circuit, thermal |
Connectors
| Connectors | Details |
|---|---|
| Input | 1 x combo jack/XLR, 1 x XLR |
| Sensitivity | -2 dBu |
| Input Impedance | 40 kOhms balanced |
| Maximum Input Level | +18 dBu |
| Ultranet Input/Link | 2 x RJ45 / Neutrik etherCON |
| Mains Supply | Neutrik powerCON, 20 A and Link: 15 A |
Controls
| Controls | Details |
|---|---|
| DSP | Rotary push-encoder and level control, buttons for process, setup, exit, enter |
| EQ Presets | Factory EQ Presets: Positioning, Array mode, FBQ |
| Display | LCD 128 x 32, blue, backlit |
| Delay | 0 to 300 ms |
| Equalization | High- and low-shelving EQ, 2 x parametric EQ |
| Limiter | Zero attack input limiter |
| Presets | 20 total presets, 19 user-definable |
| Crossover | High pass L-R 24 dB/oct |
| Protection | Lock-out function for all settings |
Network
| Network | Details |
|---|---|
| A/D Conversion | 24-bit, 44.1 / 48 kHz sample rate |
| System | Signal: 16 channels, Latency < 0.9 ms |
| Cabling | Shielded Cat 5 up to 246′ / 75 m recommended |
Power Supply
| Power Supply | Details |
|---|---|
| Current Consumption | Input: 20 A maximum, Link Output: 15 A maximum |
| Power Consumption | 200 W at 1/8 maximum power for individual product |
| Voltage | USA / Canada/ Japan: 100 to 120 VAC, 50/60 Hz |
Enclosure
| Enclosure | Details |
|---|---|
| Construction | 3/4″ / 18 mm plywood |
| Grille | Powder-coated perforated steel |
| Suspension / Mounting | Integral Suspension System, 4 x M10 points |
| Dimensions | 13.6 x 23.5 x 15.7″ / 344 x 598 x 398 mm |
| Weight | 50.7 lb / 23 kg |
