Tannoy In-Wall Speaker PCI 6DC 6″ Dual Concentric 70W Kevlar Cone
1,083.60 AED Included (5% UAE VAT)
The PCI 6DC IW features a state-of-the-art Dual Concentric driver, designed in the UK, comprising a 165 mm LF/MF driver with a blue Kevlar cone, high-excursion rubber surround, and a centrally located HF driver. This compact unit handles up to 280 Watts, offering enhanced dispersion for a balanced sound experience throughout the listening area.
Model number
PCI 6DC IW
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
The PCI 6DC IW speaker delivers exceptional performance by integrating the next generation Dual Concentric driver technology exclusive to its design. This high-definition in-wall loudspeaker is meticulously engineered in the UK, featuring a unique 165 mm (6.00″) LF/MF driver with a blue Kevlar cone and a high-excursion rubber surround. It ensures superior audio clarity and a balanced sound dispersion, enhanced by the centrally located HF drive.
Features
- 6″ Dual Concentric driver with TANNOY point-source constant directivity
- Smooth frequency response with Tulip Waveguide
- Robust blue Kevlar cone for high power handling
- Customizable performance with 3-way variable high-frequency level switch
- Continuous power handling of 70 Watts and peak power of 280 Watts
- Semi matt white finish and ultra-thin bezel for discreet integration
- Installation-friendly with integrated construction and self-aligning clamp mounting system
Specifications
| Specification | Details |
|---|---|
| Frequency response (±3dB) | 50 Hz – 20 kHz |
| Frequency response (-10dB) | 30 Hz – 20 kHz |
| Sensitivity (1W @ 1m) | 85 dB |
| Directivity factor (Q) | 4.8 averaged 1 kHz to 10 kHz |
| Directivity index (DI) | 6.8 averaged 1 kHz to 10 kHz |
| Power handling (Average) | 70 W |
| Power handling (Programme) | 140 W |
| Power handling (Peak) | 280 W |
| Recommended amplifier power | 210 W @ 8 Ω |
| Nominal Impedance (Lo Z) | 8 Ω |
| Rated maximum SPL (1 m, Lo Z) | 107 dB |
| Average SPL | 104 dB |
| Peak SPL | 110 dB |
| Crossover point | 1.6 kHz |
| Coverage angles (500 Hz) | 180° horizontal, 160° vertical |
| Coverage angles (1 kHz) | 141° horizontal, 144° vertical |
| Coverage angles (2 kHz) | 119° horizontal, 134° vertical |
| Coverage angles (4 kHz) | 92° horizontal, 87° vertical |
| LF driver diameter/material/type | 165.5 mm (6″) |
| HF driver diameter/material/type | 25.4 mm (1″) |
| Back can | Option 1: BACK CAN IW: Steel, powder coating |
| Baffle | Reflex-loaded UL94 V-0 rated ABS |
| Grille | Steel, with weather-resistant coating |
| Safety features | N/A |
| Clamping design | Security toggle clamp |
| Connectors | Phoenix Contact terminal block |
| Dimensions (HxWxD) | 315 x 221 x 105 mm (12.4 x 8.7 x 4.1″) |
| Bezel dimensions | Square: 315 x 221 mm (12.4 x 8.7″) |
| Mounting depth | 91.7 mm (3.6″) |
| Hole cutout dimensions | 299 x 203 mm (11.8 x 8″) |
| Net weight | 2.9 kg (6.4 lbs) |
| Packed quantity | 1 |
| Included accessories | Grille, paint mask, cutout template |
| Optional accessories | Option 1: BACK CAN IW Option 2: PMK 6 IW |
