Tannoy Coaxial Pendant Loudspeaker OCV 8 8 Inch 280W for Installation
1,403.85 AED Included (5% UAE VAT)
The OCV 8 is a 280-Watt pendant loudspeaker designed for high sensitivity and broadband directivity, ensuring consistent audio coverage and enhanced intelligibility. Ideal for use in aesthetically sensitive environments such as transportation terminals, shopping malls, and large commercial spaces, it offers the linear response of studio monitors and maintains excellent clarity and Sound Pressure Level (SPL).
Model number
OCV 8
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
The OCV 8 is a 280-Watt high sensitivity pendant loudspeaker that delivers wide and consistent broadband directivity with enhanced intelligibility – plus the linear response of our legendary studio monitors. Engineered specifically for aesthetically sensitive applications where consistent high quality audio coverage is required, the OCV 8 is ideally suited for airport and ground transportation terminals, shopping malls, and large double or triple height commercial floors – without compromising clarity, intelligibility or Sound Pressure Level (SPL). OCV 8 loudspeakers provide a seamless sound signature within a multi-zoned environment that benefits from additional TANNOY installation loudspeakers.
Features
- Coaxial full range pendant loudspeaker for installation applications
- 70 Watts continuous, 280 Watts peak power
- 8″ mineral loaded polypropylene driver with nitrile rubber surround for enhanced durability and long-term reliability
- 1″ ferrofluid cooled soft dome neodymium high frequency driver
- Wide constant directivity dispersion for optimum coverage
- UL 1480 certified for general signalling systems
- UV and weather resistant UL 94 V-0 ABS front with plated steel fire can enclosure
- Multiple transformer taps for 70 V and 100 V line systems or 16 Ohm direct input
- Low insertion loss 60 W line transformer with easily accessible tapping switch
- Optimised for Lab Gruppen low impedance LUCIA amplifiers with up to 8 OCV series loudspeakers per channel
- All components weather resistant to IP64 for outdoor use
- Semi matt black finish fits unobtrusively in any environment
- Powder coated perforated steel mesh grille with dust protection
- Quick and easy hanging system included for reduced installation time and cost
- Weatherproof cable gland cover to protect Phoenix* connectors and tap selector switch
Specifications
| Specification | Details |
|---|---|
| Frequency Response (-3 dB) (1) | 80 Hz – 20 kHz |
| Frequency Range (-10 dB) (1) | 50 Hz – 30 kHz |
| System Sensitivity (1 W @ 1 m) (2) | 90 dB |
| Dispersion (-6 dB) | 80 degrees conical |
| Crossover | 4.5 kHz – 3rd order LF, 2nd order HF |
| Directivity Factor (Q) | 14.4 averaged 1 kHz to 6.3 kHz |
| Directivity Index (DI) | 11.6 averaged 1 kHz to 6.3 kHz |
| Rated Maximum SPL (2) | Average: 108 dB Peak: 114 dB |
| Power Handling | Average: 70 W Programme: 140 W Peak: 280 W |
| Recommended Amplifier Power | 140 W @ 16 Ohms |
| Nominal Impedance | 16 Ohms |
| Transformer Taps (rear rotary switch) | 70 V: 60 W / 30 W / 15 W / 7.5 W / OFF & Low Impedance operation 100 V: 60 W / 30 W / 15 W / OFF & Low Impedance operation |
