Tannoy CVS 801-BK 8-Inch Coaxial Ceiling Loudspeaker 90W – Black
642.60 AED Included (5% UAE VAT)
The CVS 801-BK is a high-quality coaxial ceiling loudspeaker designed for exceptional audio performance in various environments including restaurants, hotels, houses of worship, and businesses. It features impressive power handling, wide frequency response, and low distortion. The speaker is EN 54-24 certified for fire detection and fire alarm systems, UL 1480 certified for fire-protected signaling, and UL 2043 certified for installation in air-handling spaces, ensuring adherence to rigorous safety standards.
Model number
CVS 801-BK
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
CVS 801-BK Coaxial Ceiling Loudspeaker
The CVS 801-BK is a coaxial ceiling loudspeaker engineered to provide superb audio performance in both background and foreground music sound systems. Ideally suited for a wide variety of applications, from restaurants and hotels to houses of worship and businesses of all types, the CVS 801-BK offers the power handling, wide frequency response, and low distortion typically found in more expensive products. EN 54-24 certification for fire detection and fire alarm systems makes the CVS 801-BK the perfect choice where safety is a top priority. The loudspeaker is also UL 1480 certified for fire-protected signalling systems and UL 2043 certified for air-handling spaces.
Key Features
- Coaxial full range ceiling loudspeaker for installation applications
- 90 Watts continuous, 360 Watts peak power
- 8″ polypropylene driver with butyl rubber surround for enhanced durability and long-term reliability
- 1″ ferrofluid cooled soft dome high frequency driver
- Wide constant directivity dispersion for optimum coverage
- EN54-24:2008 certified Type A
- UL 1480 certified for fire-protected signalling systems
- UL 2043 certified for air-handling spaces
- UV and weather resistant UL 94-V0 and 94-5VB ABS front with plated steel fire can enclosure
- Powder-coated aluminium mesh grille with dust protection
- Multiple transformer taps for 70 V and 100 V line systems or 8 Ohm direct input
- Low insertion loss 60 W line transformer with easily accessible tapping switch
- Semi-matte black finish fits unobtrusively in any environment
- Mounting C-ring and ceiling tile rails included
- Steel cover and strain relief clamping mechanism for fire-rated cable
Specifications
| Specification | Details |
|---|---|
| Frequency Response (+3 dB, -3 dB) | 88 Hz – 20 kHz |
| Frequency Response (-10 dB) | 65 Hz – 20 kHz |
| Sensitivity at 1m/1W | 91 dB |
| Nominal Coverage Angle | 100° |
| Directivity Factor (Q) | 10.2 (averaged 1 kHz to 6 kHz) |
| Directivity Index (DI) | 10.1 (averaged 1 kHz to 6 kHz) |
| Power Handling (LoZ) |
|
| Transformer Taps |
|
| Low Frequency Transducer | 200 mm (8″) PP cone |
| High Frequency Transducer | 25 mm (1″) coaxially mounted |
| Enclosure | Blind mount (BM) |
| Back Can | Anodized steel |
| Baffle | Reflex loaded UL 94V-0 rated ABS |
| Grille | Aluminum, powder coated |
| Safety Features | Rear enclosure safety ring for load-bearing bond |
| Clamping Design | Security toggle clamp |
| Connectors | Euroblock-style connector with screw terminals |
| Dimensions |
|
| Included Accessories |
|
| Optional Accessories |
|
| Packed Quantity | 1 pair |
