Tannoy 6″ Coaxial Ceiling Speaker CVS 6 BK Black 240W
791.70 AED Included (5% UAE VAT)
The CVS 6 BK is a compact 240-Watt ceiling loudspeaker in semi-matt black, designed to deliver exceptional audio quality for both background and foreground music in diverse settings such as restaurants, hotels, houses of worship, and various businesses. It offers studio-reference monitor features with its wide frequency response, low distortion, and high power handling, producing warm, clear, and detailed sound.
Timing confirmed at checkout.
Expert product matching.
Protected checkout in AED.
Description
The CVS 6 BK is a compact, semi matt black 240-Watt ceiling loudspeaker engineered to provide superb audio performance in both background and foreground music sound systems. Ideally suited for a wide variety of applications, from restaurants and hotels to houses of worship and businesses of all types, the CVS 6 BK offers the power handling, wide frequency response and low distortion more typically found in a studio reference monitor than a ceiling loudspeaker. The resulting sound is warm, with a nuanced and pristine clarity that envelopes the listener – without intruding.
Key Features
- Coaxial full range ceiling loudspeaker for installation applications
- 60 Watts continuous, 240 Watts peak power
- 6″ mineral loaded polypropylene driver with nitrile rubber surround for enhanced durability and long-term reliability
- 0.75″ ferrofluid cooled soft dome neodymium high frequency driver
- Wide constant directivity dispersion for optimum coverage
- UL 1480 certified for fire-protected signalling systems
- UL 2043 certified for air-handling spaces
- UV and weather resistant UL 94 V-0 ABS front with plated steel fire can enclosure
- Multiple transformer taps for 70 V and 100 V line systems or 6 Ohm direct input
- Low insertion loss 60 W line transformer with easily accessible tapping switch
- Semi matt black finish fits unobtrusively in any environment
- Powder coated perforated steel mesh grille with dust protection
- Mounting C-ring and ceiling tile rails included
- Phoenix* connector with steel cover and strain relief clamping mechanism for fire rated cable
Specifications
| Specification | Details |
|---|---|
| Frequency response | 79Hz – 21kHz (-3dB) 60Hz – 24kHz (-10dB) |
| System Sensitivity | 91dB (1W = 2.45V for 6 Ohm) (1W at 1m) |
| Nominal Coverage Angle | 90 degrees conical |
| Coverage Angle | 93 degrees (1kHz to 6kHz) |
| Directivity Factor (Q) | 7.7 averaged 1kHz to 6kHz |
| Directivity Index (DI) | 8 averaged 1kHz to 6kHz |
| Rated Maximum SPL | 109 dB (average) 115 dB (peak) |
| Power Handling | Average: 60W Programme: 120W Peak: 240W |
| Recommended Amplifier Power | 120W at 6 Ohms |
| Nominal Impedance | 6 Ohms |
| Transformer Taps | (via front rotary switch): 70V: 60W / 30W / 15W / 7.5W / OFF & low impedance operation 100V: 60W / 30W / 15W / OFF & low impedance operation |
| Low Frequency | 150mm (6.00″) mineral loaded polypropylene ICT |
| High Frequency | 19mm (0.75″) |
| Cable Entry Options | Cable clamp & squeeze connector for conduit up to 22 mm |
| Connectors | Removable locking connector with screw terminals with “loop through” facility |
| Safety Agency Ratings | UL-1480, UL-2043, CE |
| Hole Cutout Diameter | 250 mm (9.84″) |
| Front of ceiling to rear of back can | 246.5 mm (9.70″) |
| Front of ceiling to top of safety loop | 258.5 mm (10.18″) |
| Enclosure | Back can: Zinc plated steel Baffle: Reflex loaded UL 94V-0 rated ABS Grille: Steel, with weather resistant coating |
| Safety Function | Safety ring located at rear of enclosure for load bearing safety bond |
| Clamping Design | Security toggle clamp |
| Dimensions (Dia.xL) | 11 x 10.5″ (279.40 x 266.70 mm) |
| Weight | 12.6 lbs (5.72 kg) |
