Tannoy Ceiling Speaker CMS 603DC BM 6-Inch 320W Dual Concentric Driver
1,323.00 AED Included (5% UAE VAT)
The CMS 603DC BM is a 320-Watt high sensitivity loudspeaker featuring CMS 3.0 technology, equipped with a proprietary 6" Dual Concentric driver on an Omnimagnet Torus Ogive Waveguide. This UL certified speaker offers wide broadband directivity, enhanced intelligibility, and linear response.
Model number
CMS 603DC BM
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
CMS 603DC BM Full Bandwidth Ceiling Loudspeaker
The CMS 603DC BM is a full bandwidth 320-Watt high sensitivity loudspeaker that utilises our third generation Ceiling Monitor System technology (CMS 3.0). Thanks to an all-new proprietary 6″ Dual Concentric point-source driver with Omnimagnet technology on a Torus Ogive Waveguide, the UL certified CMS 603DC BM delivers wide and consistent broadband directivity with enhanced intelligibility – plus highly accurate and linear response.
Features
- Full range ceiling loudspeaker for installation applications
- 80 Watts continuous, 320 Watts peak power
- Next generation 6″ Dual Concentric driver featuring Omnimagnet technology
- Torus Ogive waveguide for improved high frequency response and directivity
- Blind Mount version supplied with acoustically enhanced zinc plated steel back can
- Integrated single unit construction for ease of installation
- UL 1480 certified for general signalling systems
- UL 2043 certified for air-handling spaces
- Multiple transformer taps for 70 V and 100 V line systems or 16 Ohm direct input
- Low insertion loss 60 W line transformer with easily accessible tapping switch
- Optimised for Lab Gruppen low impedance LUCIA amplifiers with up to 8 CMS series loudspeakers per channel
- Semi matt white finish fits unobtrusively in any environment
- Powder coated UV resistant perforated steel mesh grille with dust protection
- Removable magnetic grille for custom painting
- Optional ARCO designer grilles available for minimal architectural impact
- Self-aligning 4 way clamp mounting system
- Mounting C-ring and ceiling tile rails included
Specifications
| Specification | Details |
|---|---|
| Frequency response (-3 dB) BM Backcan | 75 Hz – 30 kHz |
| Frequency range (-10 dB) BM Backcan | 50 Hz – 30 kHz |
| System sensitivity (1 W @ 1 m) | 91 dB (1 W = 4 V for 16 Ohms) |
| Nominal coverage angle | 90 degrees conical |
| Power handling | 80 W average, 160 W programme, 320 W peak |
| Recommended amplifier power | 160 W @ 16 Ohms |
| Nominal impedance | 16 Ohms |
| Rated maximum SPL | 110 dB average, 116 dB peak |
| Transformer taps | 70 V: 60 W / 30 W / 15 W / 7.5 W, 100 V: 60 W / 30 W / 15 W |
| Driver | 165 mm (6.5″) Dual Concentric driver with Omnimagnet technology |
| Enclosure material | Zinc plated steel |
| Grille material | Steel with weather resistant coating |
| Certifications | UL-1480, UL-2043, CE |
| Dimensions | Bezel diameter: 274 mm, Depth: 255.8 mm (BM model) |
| Weight | 6.6 kg (BM model), 3.8 kg (PI model) |
| Included accessories | C-Ring, tile-bridge kit, paint mask, cut-out template, grille |
| Optional accessories | Plaster ring, Arco grille |
