Soundcraft EPM12 12-Channel Analog Mixer with GB30 Mic Preamps (UK Version)
2,485.43 AED Included (5% UAE VAT)
The Soundcraft EPM 12 is a versatile 12-channel audio mixer designed for recording studios, live sound reinforcement, and touring musicians, featuring 12 mono inputs with 1/4" phone and XLR connections, 2 stereo inputs with L/R 1/4" phone connections, and high-quality GB30 microphone preamps for detailed audio capture.
Model number
EPM12
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
Soundcraft EPM 12 Audio Mixer
The Soundcraft EPM 12 offers a high-quality, professional-grade mixing solution for recording studios, venues, and touring musicians. This audio mixer boasts 12 mono and 2 stereo input channels, providing versatile connectivity to suit a variety of sound reinforcement and recording applications. Encased in a compact and mobile enclosure, the EPM 12 is designed to deliver an impressive performance.
Features
- 12 Mono & 2 Stereo Input Channels
- Equipped with 12x GB30 Microphone Preamplifiers
- Ideal for Both Recording and Live Sound Environments
- Compact Mobile Enclosure for Easy Transportation
Specifications
| Specification | Details |
|---|---|
| Total # Of Inputs | 12x Mono 2x Stereo |
| Mic/Line Inputs | 12x Line Mono: 1/4″ TRS Phone 2x Line Stereo: L/R 1/4″ TRS Phone 12x Microphone: 3-pin XLR |
| Stereo Line Inputs | 2x Stereo: L/R 1/4″ TRS Phone |
| In-Line Inputs/Returns | No |
| AUX Sends | 2x Aux Sends |
| AUX Returns | No dedicated returns |
| Inserts | 1/4″ TRS Phone – Mono Inputs, Main Stereo Output |
| BUS (Group) Outputs | Stereo Output Only |
| 2 Trk Master I/O | Mix L/R: Stereo Paired L/R RCA Phono |
| ALT I/O | No |
| Monitor Outputs | Monitor: L/R Stereo Paired 1/4″ TRS Phone |
| EQ Section | Mono Inputs +/- 15 dB Lo: 80 Hz Mid: 150 Hz – 3.5 kHz (swept) Hi: 12 kHz Q: 1.5 Stereo Inputs +/-15 dB Lo: 80 Hz Mid: 720 Hz Hi: 12 kHz |
| Solo/Mute | All Input Channels |
| Channel Level Control | 100 mm Faders |
| Trim/Gain Control | Rotary Potentiometers |
| Phantom Power | +48 V Phantom |
| Metering | 10-Segment L/R Peak LEDs +48 V Phantom Power LED PFL Active LED Power Indicator LED |
| Frequency Response | 20 Hz to 20 kHz +/-1.5 dB |
| Dynamic Range | Not specified by manufacturer |
| Signal-to-Noise Ratio | Noise (22 Hz – 22 kHz measurement bandwidth) Mic EIN @ max gain, 150 ohms source impedance -127 dBu Mix @ max, faders to down <-85 dBu |
| Total Harmonic Distortion (THD) | Mic sensitivity 30 dB, +14 dBu @ mix output: <0.02% |
| Power Supply | Integral lightweight switched-mode PS AC mains supply: 85-270 V AC, 50/60 Hz universal input Power Consumption: Less than 20 W |
| Dimensions | 17 x 3.56 x 14.25″ (432 x 90.5 x 362 mm) |
| Weight | 12.13 lb (5.5 kg) |
