Ortofon Concorde Gold DJ Turntable Cartridge with Pro E Stylus 6 mV
739.00 AED Included (5% UAE VAT)
The Concorde Gold cartridge is specially designed to commemorate the Technics SL-1200LTD and SL-1200GLD turntables, offering superior sound quality and an aesthetic match for these limited edition models. It is compatible with a wide range of turntables, making it a versatile choice for DJs seeking both performance and style.
Model number
Concorde Gold
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
Concorde Gold DJ Cartridge: Unmatched Audio Quality
The Concorde Gold cartridge is a tribute to the iconic Technics SL-1200LTD and SL-1200GLD turntables. With its luxurious gold plating and superior Pro E diamond stylus, this cartridge is designed to offer the finest sound quality for DJs and audiophiles. It’s compatible with a wide range of turntables, making it a versatile choice for any setup.
Experience the excellence of the Concorde Gold with its meticulously designed features that provide a sublime audio experience. From the first use, the cartridge delivers an exceptional sound performance, worthy of its flagship status.
Gold Technical Data
- Stylus Type: Special Elliptical
- Tracking Force: 3.0 g (30 mN)
- Output Voltage: 6 mV
- Frequency Range: 20-20,000 Hz +/- 2 dB
Key Features
| Specification | Details |
|---|---|
| Output Voltage at 1000Hz, 5cm/sec. | 6 mV |
| Channel Balance at 1kHz | 1.5 dB |
| Channel Separation at 1kHz | 23 dB |
| Channel Separation at 15kHz | 15 dB |
| Frequency Range at -3dB | 20-22,000 Hz |
| Frequency Response | 20-20,000 Hz +/- 2 dB |
| Tracking Ability at 315Hz (recommended force) | 80 μm |
| Compliance, Dynamic Lateral | 7 μm/mN |
| Stylus Tip Radius | r/R 13/25 μm |
| Tracking Force Range | 2.0-5.0 g (20-50 mN) |
| Tracking Force Recommended | 3.0 g (30 mN) |
| Tracking Angle | 20° |
| Internal Impedance, DC Resistance | 750 Ohm |
| Internal Inductance | 450 mH |
| Recommended Load Resistance | 47 kOhm |
| Recommended Load Capacitance | 200-600 pF |
| Cartridge Weight | 18.5 g |
