Midas DL32 Digital Stage Box, 32 Input, 16 Output, 32 Mic Preamps, ULTRANET
6,715.80 AED Included (5% UAE VAT)
The DL32 digital stage box features 32 Midas PRO Series remote-controllable mic preamps and 16 balanced analog XLR returns, all connected via a single Cat 5e cable up to 100 meters, streamlining the live-entertainment production workflow with advanced AES50 SuperMAC technology.
Model number
DL32
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
DL32 Digital Stage Box
The DL32 is a highly affordable, I/O packed digital stage box designed to revolutionize live-entertainment production workflow. It’s perfect for connecting onstage talent with your Front of House (FOH) console and offers seamless integration into modern audio setups using a single Cat 5e cable.
Features
- 32 remote-controllable Midas PRO Series microphone preamplifiers with 48 V phantom power.
- 16 electronically balanced low impedance line level outputs.
- ULTRANET personal monitoring system connectivity for enhanced in-ear monitoring.
- Dual AES50 SuperMAC ports for cascading additional stageboxes without a merger or router.
- MIDI In/Out for efficient control between Midas consoles and on-stage MIDI devices.
- 2 AES-3 ports for direct connection to PA system controllers with digital inputs.
- Rugged 3U rackmount chassis ideal for portable applications.
Specifications
| Specification | Details |
|---|---|
| Type | Digital Stage Box |
| Compatibility | AES50/Ultranet systems |
| Channels | 32 x 16 |
| Inputs – Mic Preamps | 32 x XLR |
| Phantom Power | Yes |
| Outputs – Main | 16 x XLR (line) |
| Inputs – Digital | 2 x EtherCon (AES50) |
| Outputs – Digital | 2 x EtherCon (AES50), 2 x XLR (AES/EBU), 2 x Optical Toslink (ADAT) |
| Data I/O | 1 x Ethernet (Ultranet monitoring) |
| USB | 1 x Type B |
| Computer Connectivity | USB, Ethernet |
| MIDI I/O | In/Out |
| Rackmountable | 3U |
| Dimensions | Depth: 9.5″, Width: 19″ |
| Weight | 12.5 lbs. |
