Midas DL16 Digital Stage Box with 16 Mic Preamps and 8 Outputs for Live Sound
4,401.60 AED Included (5% UAE VAT)
The DL16 Stage Box offers 16 award-winning microphone preamplifiers with switchable +48 V phantom power, 8 balanced analogue XLR returns, and an integrated ULTRANET output for BEHRINGER P16-M personal monitor mixers, along with ADAT-compatible connectivity. Ideal for expandable inputs and efficient cabling, it requires just a single CAT5 cable per stage box.
Model number
DL16
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
DL16 Stage Box
Experience the forefront of digital mixing technology with the DL16 Stage Box. Designed to meet the demands of live entertainment production, this versatile unit boasts 16 of our award-winning microphone preamplifiers with switchable +48 V phantom power. Whether you need more inputs or a streamlined setup, the DL16 offers unmatched flexibility with easy connectivity options.
The DL16 features an integrated ULTRANET output, allowing seamless connection to BEHRINGER P16-M personal monitor mixers, and provides dual AES50 SuperMAC ports for cascading additional stage boxes. Its rugged 2U rackmount chassis ensures durability, making it an essential tool for both portable and fixed installations.
Key Features
- 16 Midas PRO microphone preamplifiers with switchable 48 V phantom power
- 8 electronically balanced low impedance line level outputs
- ULTRANET personal monitoring system connectivity
- Dual AES50 SuperMAC ports for cascading additional stage boxes
- Dual ADAT outputs providing 16-channel digital output
- Remote operation via shielded CAT5e cable up to 100 meters
- All settings programmable from front panel controls or console
- Status indicator LEDs on front panel
- Headphones output assignable to any input or output for monitoring
- MIDI In/Out for communication with Midas M32 Series console
- Neutrik etherCON AES50 and ULTRANET network ports
- Rugged 2U rackmount chassis
- Auto-ranging universal switch-mode power supply
Specifications
| Specification | Details |
|---|---|
| Type | Digital Stage Box |
| Compatibility | AES50 / Ultranet systems |
| Channels | 16 x 8 |
| Inputs – Mic Preamps | 16 x XLR |
| Phantom Power | Yes |
| Outputs – Main | 8 x XLR |
| Outputs – Digital | 2 x Optical Toslink (ADAT) |
| Data I/O | 2 x EtherCON (AES50), 1 x EtherCON (Ultranet) |
| USB | 1 x Type B |
| Computer Connectivity | USB, Ethernet |
| MIDI I/O | In/Out |
| Headphones | 1 x 1/4″ |
| Rackmountable | 2U |
