Lab Gruppen PLM 20K44 20,000W 4-Channel Amplifier with Lake DSP for Touring
49,893.90 AED Included (5% UAE VAT)
The PLM 20K44 features a 4-in, 4-out configuration with industry-standard Dante networking, serving as the benchmark for powered loudspeaker management systems. As the successor to the renowned PLM 20000Q, it offers double the processing power with the latest Lake Controller 6.3 release, making it ideal for professional touring applications.
Model number
PLM 20K44 BP
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
PLM 20K44 Powered Loudspeaker Management System
The PLM 20K44 combines four channels of powerful amplification, advanced signal processing, and robust audio management. Perfectly integrating networking, audio I/O, amplifiers, and power supply, this system provides comprehensive control and monitoring capabilities with industry-standard Dante® networking.
With its roots in the legendary PLM 20000Q, the PLM 20K44 adds a 4-in/4-out configuration and doubles the processing power, ensuring unparalleled performance and reliability in touring applications.
Features
- 20,000 Watt amplifier with 4 flexible output channels
- Integrated dual redundant Dante digital audio networking
- Lake signal processing for superior loudspeaker management
- Four channels of powerful amplification with efficient cooling
- Comprehensive protection features and monitoring capabilities
- 100 user presets for quick and easy setup
Specifications
| Specification | Details |
|---|---|
| Processing / Network | Lake / Dante |
| Number of amplifier channels | 4 |
| Total burst power all channels | 20000 W |
Max Output Power (All Channels Driven)
| Impedance | Power |
|---|---|
| 2 ohms | 4,400 W |
| 2.67 ohms | 5,000 W |
| 4 ohms | 4,400 W |
| 8 ohms | 2,300 W |
| 16 ohms | 1,150 W |
| Hi-Z 70 V | 3,300 W |
| Hi-Z 100 V | 4,700 W |
Audio Performance
| Parameter | Value |
|---|---|
| THD + N 20 Hz – 20 kHz for 1 W | < 0.05 % |
| Dynamic range | > 114 dB |
| Channel separation (at 1 kHz) | > 70 dB |
Dimensions
| Parameter | Value |
|---|---|
| Rack rail to rear panel | W: 483 mm, H: 88 mm, D: 424 mm |
| Overall depth | 498 mm |
| Weight | 17 kg |
