Description

Description

Unveiled as the modern evolution of the classic 1963 model, the La Scala AL6 packs Klipsch’s horn-loaded magic into a refined floorstanding speaker built for high efficiency and low distortion. The AL6 is a three-way horn-loaded system where each driver is mated to a dedicated horn optimized for its passband. It features the K-771 compression driver with an extended phase plug for improved high-frequency dispersion, a larger K-1133-HP 3″ midrange compression driver on the new K-406M Tractrix horn with Mumps technology for improved coverage and clarity, and a K-281 12″ woofer housed in a newly designed horn-loaded, vented enclosure for significantly enhanced bass performance. An optional Heritage Active DSP crossover is available for users seeking time/phase alignment and advanced EQ tuning. The speaker is available in premium veneers (American Walnut, American Auburn, Black Ash) with a silver metallic grille and is handcrafted in the USA.

Specification Details
Model La Scala AL6
Brand Klipsch
Frequency Response 40 Hz – 19 kHz (±4 dB), 1/4 space anechoic
Sensitivity 103 dB (Pink noise, 2.83 V @ 1 m, 40 Hz–19 kHz)
Power Handling (Continuous / Peak) 100 W / 400 W
Maximum SPL 120 dB (Pink noise, 1 m, 20 V, 40 Hz–19 kHz)
Nominal Impedance 8 Ω (3.2 Ω minimum @ 70 Hz)
Crossover Frequencies 425 Hz, 2,900 Hz
High-Frequency Driver K-771 compression driver with extended phase plug on a K-792 horn
Midrange Driver K-1133-HP 3″ compression driver on K-406M Tractrix horn with Mumps technology
Low-Frequency Driver K-281 12″ woofer in a horn-loaded, vented system
Enclosure Material Veneered MDF
Grille Cloth Silver Metallic
Inputs 5-way metal binding posts
Dimensions (H × W × D) 39.125″ (99.4 cm) × 24.5″ (62.25 cm) × 25.5″ (64.7 cm)
Weight 205 lbs (93 kg)
Finishes American Walnut, American Auburn, Black Ash (silver metallic grille)
Optional Accessories Heritage Active DSP Crossover (sold separately)
Handcrafted Made in USA
SKU AL6
