Klark Teknik DN4816U StageConnect Interface with 32-Channel USB Audio I/O
1,071.00 AED Included (5% UAE VAT)
The Klark Teknik DN4816U is a versatile interface box engineered for seamless audio integration across StageConnect devices, Behringer Ultranet, and USB audio on a PC. It supports 32 channels, enabling USB audio transmission to Behringer P16 mixers, functions as an input box for various mixers, and facilitates direct recording to a DAW. Utilizing a single XLR cable for multi-channel audio, it offers scalable connectivity options and automatic channel allocation when daisy-chained with DN48XX Series devices.
Model number
DN4816U
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
Klark Teknik DN4816U: Multi-Channel Audio Interface
The Klark Teknik DN4816U is your go-to universal compact interface designed for seamlessly interconnecting 32 channels of audio between StageConnect devices, Behringer Ultranet, and USB audio on your PC. This versatile interface box caters to various audio setups including personal monitor mixers, input boxes, and direct recording to DAW via a Behringer WING.
Key Features
- DI Box sized, offering scalable connectivity for StageConnect and Behringer Ultranet systems
- 32-channel StageConnect audio transmission with sub-millisecond latency, 24-Bit uncompressed PCM audio
- Asynchronous 32-channel sample rate conversion with 0.4 ms latency
- Bi-directional audio configurations with control data and 12 VDC/18 W remote power
- Compatibility for transmitting StageConnect or USB signals to personal monitoring mixers or speakers
- Master and Slave modes for flexible audio exchange within a StageConnect device chain
- Behringer Ultranet to StageConnect or USB stream conversion
- External power supply to support stand-alone functionalities and remote power output
Specifications
| Specification | Details |
|---|---|
| StageConnect Bus Capacity | 32 channels, 24-Bit PCM audio |
| I/O Latency | 0.1 ms |
| Ultranet Connectors | 2 x RJ45 |
| Shielded CAT5e Cable Max Length | 75 m |
| StageConnect Connectors | 1 XLR male, 1 XLR female |
| Shielded Balanced 110-Ohm DMX Cable Max Length | 40 m |
| USB Connector | Type B |
| USB Audio In/Out Configurations | 32/0, 24/8, 16/16, 8/24 channels |
| USB Audio Class 2 Compatibility | Windows 10 (ASIO/WDM), macOS (CoreAudio), Linux |
| Power Supply | 12 V DC / 2.5 A, 30 W adapter; Remote power input (Slave XLR) and output (Master XLR), 12 V DC / 1.5 A, 18 W |
| Power Consumption | 9 W |
| Operating Temperature Range | 5° – 45° C (41° – 113° F) |
| Dimensions | 118 x 63 x 112 mm (4.7 x 2.5 x 4.4 in) |
| Weight | 0.71 kg (1.57 lbs) |
