JBL Professional 2-Channel Power Amplifier CSA2120 120W per Channel for Installed Sound
2,740.00 AED Included (5% UAE VAT)
The JBL CSA2120 is a 2-channel installed sound power amplifier with 120W per channel at 4 or 8 ohms, featuring dual summing RCA and 3-pin Euroblock inputs, selectable limiter, 70Hz high-pass filter, and a 4-pin Euroblock output. It includes auto-standby, over-heat and low-voltage protection, rackmount kit, front-panel volume controls, and LED indicators, and operates on a switch-mode universal power supply.
Model number
CSA2120R
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
JBL CSA2120 2-Channel Installed Sound Power Amplifier
The JBL CSA2120 Installed Sound Power Amplifier is designed to meet the demands of installed sound applications with its 120 watts of output per channel at 4 or 8 ohms. With features like dual summing RCA inputs, a 3-pin detachable Euroblock input for each channel, selectable limiters, and high-pass filters at 70Hz, the CSA2120 ensures versatile and high-quality sound performance.
It includes cutting-edge protections like over-heat and low-voltage safeguards, and its auto-standby mode efficiently conserves energy by disabling the amplifier when no signal is detected. The unit also boasts front-panel channel volume controls and indicators for clipping, signal, and power status, powered by a universal switch-mode power supply.
Key Features
| Specification | Details |
|---|---|
| Number of Channels | 2 |
| Power Rating | 120 W per Channel (4 / 8 Ohms) |
| Load Impedance / Voltage | 4 / 8 Ohms |
| Input Sensitivity | 1.4 Vrms (at 8 Ohms) |
| Input Impedance | 20 Kilohms (Balanced), 10 Kilohms (Unbalanced) |
| SNR | > 100 dBA (at 8 Ohms) |
| THD+N | < 0.5% |
| Crosstalk | 70 dBA (1 kHz), 50 dBA (20 kHz) Below Rated Power |
| I/O | 2 x 2RCA Input, 2 x Euroblock 3-Pin Input, Euroblock 4-Pin Output |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Dimensions | 8.2 x 1.7 x 7.0″ / 20.9 x 4.4 x 17.8 cm |
| Package Weight | 4.285 lb |
| Box Dimensions | 12.15 x 11.15 x 5.15″ |
