JBL Cinema Mid/High-Frequency Module 5732-M/HF 700W for Cinema Systems
15,086.26 AED Included (5% UAE VAT)
The JBL Professional 5732-M/HF is a passive mid-/high-frequency module designed as a replacement for the 5732 3-way tri-amped cinema loudspeaker system, featuring two 8" Differential Drive mid-drivers and a 4" neodymium high-frequency compression driver with waveguides for enhanced coverage, power handling, and low distortion.
Model number
5732-M/HF
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
JBL Professional 5732-M/HF Mid/High Frequency Component
The JBL Professional 5732-M/HF passive mid-/high-frequency component serves as a replacement module for the 5732 3-way tri-amped cinema loudspeaker system. It delivers exceptional coverage, maximum power handling, and consistent acoustic output with minimal distortion. Ideal for cinema applications, this module boasts advanced technology to enhance audience experience.
Key Features
- 700W midrange with two 8″ Differential Drive transducers
- 4″ neodymium high-frequency compression driver with damped titanium diaphragm
- Molded Optimized Aperture Waveguide technology for low distortion
- JBL patented Screen Spreading Compensation (SSC)
- Focused coverage technology for improved sound projection
- Flat front waveguide design facilitating easy baffle wall installation
Specifications
| Active or Passive | Passive |
| Speaker Configuration | 2-Way |
| Power Handling | 700 W for 2 hours / 150 W |
| Impedance | 4 Ohms (Minimum, Nominal) / 8 Ohms (Minimum, Nominal) |
| High-Frequency Driver | 1 x 1.5″ / 38.1 mm Compression Driver |
| High-Frequency Voice Coil | 4″ / 101.6 mm |
| Low-Frequency Driver | 2 x 8″ / 203.2 mm Woofer |
| Low-Frequency Voice Coil | 3″ / 76.2 mm |
| Magnet Type | Neodymium (High-Frequency) |
| Sensitivity | 110 dB SPL / 115 dB SPL |
| I/O Connectors | Barrier Strip |
| Dimensions (WxHxD) | 41.5 x 30 x 17.8″ / 1054.1 x 762 x 452.12 mm |
| Weight | 48 lb / 21.8 kg |
| Package Weight | 70 lb |
| Box Dimensions (LxWxH) | 44.5 x 35 x 22.5″ |
