Allen & Heath AB168 Portable Audiorack 16 Mic Inputs 8 Outputs for Live Sound
5,727.00 AED Included (5% UAE VAT)
The AB168 Portable Audiorack from Allen & Heath is a durable audio interface stage box tailored for GLD and Qu digital mixing systems. It offers sixteen mic/line XLR inputs, individual LED phantom power indicators, eight XLR outputs, and connects to the mixer over a single Cat5 cable using dSNAKE protocol. The unit supports daisy-chaining with additional AB168 or AR2412 Audioracks and ME personal monitor mixing systems. Designed for stage use, it features rubber bumpers, a lightweight 10.6 lb build, a carry handle, and optional rackmounting.
Model number
AB1608
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
Allen & Heath AB168 Portable Audiorack
The AB168 Portable Audiorack from Allen & Heath is a robust audio interface stage box designed for seamless integration with GLD and Qu digital mixing systems. It is ideal for live sound production and installations, offering a high degree of flexibility and performance.
Key Features
- 16 mic/line XLR inputs with high-quality mic preamps and LED phantom power indicators
- 8 XLR outputs
- Connects to a mixer with a single Cat5 cable using dSNAKE protocol
- Expander port for daisy-chaining with additional Audiorack units or connecting to ME personal monitor systems
- Rugged design with rubber bumpers for stage use, and optional rackmount capability
- Lightweight at 10.6 lb with a carry handle for easy transport
- Auto firmware updates to synchronize with the GLD system
Specifications
| Specification | Details |
|---|---|
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Power Consumption | 20 W (Maximum) |
| Operating Temperature | 32 to 95°F / 0 to 35°C |
| Dimensions | 16.2 x 7.4 x 6.1″ / 41.1 x 18.8 x 15.5 cm |
| Weight | 10.6 lb / 4.8 kg |
| Package Weight | 13.45 lb |
| Box Dimensions (LxWxH) | 23.228 x 13.465 x 13.15″ |
